Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 45
M1.O3*: TEMPMax > 23.98 G
M1.O4*: TEMPCnt > 6.00 G
M1.O5: TEMPSTD > 0.00 G
End M1*: TEMP
Note that there’s an arrow on the menu item M1.O1 and the other output values. This arrow
indicates that you can press RIGHT for more details. M1.O1 is an output value for the
measurement. In the prior display, since the MeasType is Average which produces 5 output
values: Average, MIN, MAX, Count (CNT), Standard deviation (STD). Other MeasType will define
other outputs based on the way the MeasType was defined. The “>” to the right of the name
suggests there’s more to see for each output by pressing RIGHT.
Operating the 8310
Main Menu
The main menu for the 8310 displays important operational information and is the starting point
for all 8310 users. The terminal version of the menu is shown below. Note that this menu
shows the station name, date and time, recording status, data for selected sensors, and provides
navigation into the logs, setup, diagnostics, etc. The main menu will display an added first line
“Errors present” if there are errors that require user attention.
Sutron 8310: Main Menu
Station 8310C 09/24/2010 13:56:34
Recording is ON+TX 9 Meas Active
Alarm Status: NORMAL
M1.O1*: TEMP > 23.971 C G
M2.O1: VBAT > 13.25 G
M3.O1: VBAT_HR > 0.00 U
M4.O1*: AirTemp > 23.53 G
M5.O1: RelHumid > 46.20 G
M6.O1*: Stage > 9.95 G
M7.O1: DewPoint > 18.44 G
M8.O1: testdata > 25.46 G
M9.O1: Stage > 0.00 U
Logged Data >
Station Setup >
Terminal Operations >
Diagnostics >
End Main
RIGHT to view log | ENTER to measure live
Errors
If the 8310 encounters a problem or error in the course of its operation, it will activate the
“Errors present” item at the top of the main menu. If you should see this item, press RIGHT to
see the errors. Use the troubleshooting section to help understand and resolve each error. You
should clear the errors before leaving the station.
Recording
The main menu will show “Recording is OFF”, “ON” or “ON+TX”. When Recording is OFF, the
8310 is not automatically collecting data or transmitting the data. It is waiting to be setup
and/or have the Recording turned ON. When Recording is ON it is automatically collecting data
