Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 97
Max
For input and holding registers of value type short or ushort, Min and Max are used to scale the
output into the integral range 0 – 65535 (the range of the data type used to communicate
register data back to the Modbus master device). Typically, you enter into Max the highest value
you expect this block to contain.
LiveReading
When “Yes”, a “live reading” is performed when a request to read or write the data is received.
Station Setup/Measurements/Mx/Mx.Ox/Telemetry Settings
Every output has a sub-menu for each telemetry device installed. The sub-menu is named after
the type of telemetry installed, e.g., “Iridium COM2: Iridium Settings”, or “Satlink COM3:
Selftimed Settings”, etc.
Note: this menu can typically be accessed from the associated communications device submenu
named “Select Output Settings”. For example, the Satlink Selftimed Settings menu can be
accessed via Communications/Satlink/SelfTimed/SelectOutputSettings. Changes can be made
from either menu.
Here is a list of telemetry devices that may be installed:
DIRECT
Direct connection over COM port to PC, etc.
GPRS
GPRS modem
IRIDIUM
Iridium modem
MODEM
Sutron voice modem, or other Hayes compatible data modem
RADIO
Radio used for line-of-sight serial communications
RS485
Direct connection over RS485 comm link
SATLINK
Sutron Satlink transmitter
SSP
Direct connection over COM port to XConnect, Tempest, etc.
LAN
LAN connection
VOICE
Sutron voice modem
TxContent, DataInterval, DataTime, NumVals, Sequence
These properties determine what data is included in transmissions, and its sequence in the
transmission (if applicable to the selected format). The value of TxContent can be All, Individual,
or Exclude as described below. To change the setting press SET/ENTER and select the desired
value.
TxContent
Property
Description of Property
All
All the data logged for the output since the last
transmission will be transmitted
Sequence
Sequence determines the order of this output in the
transmission message.
Individual
Individual values logged for the output since the last
transmission will be transmitted.
DataInterval
the time interval between readings from the 8310 log
DataTime
the time at which to begin extracting data from the log
in order to build a message
