Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 98
No. of data items for each parameter taken from 8310
log and encoded in each self-timed transmission
Sequence determines the order of this output in the
transmission message.
Do not transmit this output.
Note: When Pseudobinary B (an interleaved format) is the selected format, the user defines a
NumVals setting for all outputs in the device Communications menu, and the meaning of the
TxContent property on each output changes: A TxContent value of “Last” no longer means just
the last value, but the last NumVals values. A TxContent value of “All” no longer means all values
since last transmission, but all values up to NumVals.
TxAlarmMode
The TxAlarmMode property is used to control when an alarm transmission occurs. When
TxAlarmMode is TxIn, a transmission occurs when the output enters alarm. When TxAlarmMode
is TxInAndOut, a transmission occurs when the output both enters and exits alarm.
Additional Telemetry Settings
The following sections describe what other settings are available for each of the different
possible telemetry device types that support additional settings.
Voice Settings
The following properties are available under the VOICE COMx: Voice Settings menu item for
each output in the system.
PrefixPhrase
This phrase is spoken by the speech modem before the value.
SuffixPhrase
This phrase is spoken by the speech modem after the value.
Station Setup/Measurements/ Mx/Simulate
The Simulate menu allows inputs of the measurement to be manually entered and the
calculated output values to be observed. This feature will only be displayed for measurements
which support live measurements and have outputs.
A typical simulation menu is show below:
Simulate M4: F-BP-CZ11
M4.I1: Freq (Raw) 4.0
M4.I1: Freq 4.0
M4.I2: TempC (Raw) N/A
M4.I2: TempC 22
M4.I3: BP (Raw) 0
M4.I3: BP 0
M4.O1+: -Out 14.95 G
M4.O2+: -Digits 4.0 G
M4.O3+: -TempC 22.00 G
M4.O4+: -Freq 63.25 G
End Simulate
