Sutron Corporation 8310 & 7310 Users Manual 8800-1125Rev. 2.7 (BETA) 4/16/2014 pg. 99
For each input, both the raw unprocessed value and the post-processed value will be displayed.
You may change either by selecting it and pressing SET, and the outputs will automatically start
recalculating. While simulation is taking place you will see “+” appear in the output names (as
shown in the sample screen). Scheduled measurements will continue to take place normally,
and an “*” may appear in one or more of the output names to indicate that one is occurring.
Simulation may delay a scheduled measurement but only for the time needed to compute the
new outputs.
If you set the raw value of an input, then the post-processed value will be simulated and
displayed. If instead you set the post-processed input value, the raw value will display as “N/A”,
as the input processing cannot be reversed.
Any input values you enter will be remembered until the next reboot.
Station Setup/Communications
The Station Setup/Communications menu shows the communications ports that are in the
system. The menu shows the type of communications configured for each device, and the
status of each device. Press RIGHT to see and optionally change the detailed settings for each
device. Press SET to change the type of device (note: COM1 is always type DIRECT and cannot
be changed).
A typical communications menu is shown below:
Communications (5)
COM1: (Standby-On) ► DIRECT
COM2: (Standby-On) ► VOICE
COM3: ► NO CONNECT
COM4: ► NO CONNECT
LAN (Standby-On) ►
End Communications
LAN Setup
See Station Setup/Communications/LAN Setup
Station Setup/Communications/COMx DIRECT | RADIO | SSP
These are the detailed settings for communications types DIRECT, RADIO and SSP. This menu
has the following items:
Enabled
BaudRate
MasterID
TXNormalRate
TXAlarmRate
SSP Settings > details
CarrierDelay
ReplyDelay
