5-22
OTHER CONTROLS AND EQUIPMENT
79MS0-14E
Automatic Heating and Ai
r Conditioning System
(Climate Control)
Description of Controls
79MH0529
(1)
(2)
(9)
(3)
(6)
(7)
(8)
(4)
(5)
(1)
T
emperature selector
(2)
Blo
wer speed selector
(3)
Air intake selector
(4)
Air fl
ow selector
(5)
Defrost switch
(6)
Air cond
itioning switch
(7)
“OFF” switch
(8)
“AUTO” switch
(9)
Display
141
143
