75
SPARK PLUG
Remove the spark plugs as follows:
1. Remove the motor cover.
2. Remove the ignition coil bracket bolts and
ignition coil brackets 1.
3. Remove the bolt securing the ignition coil.
4. Pull out the ignition coil.
NOTE:
Turn the ignition coil
A clockwise as shown in
the figure to remove.
The installation is a reverse procedure of the
removal.
NOTICE
When servicing the iridium/platinum spark
plugs, do not touch the center electrode, as it
is easy to damage.
Do not touch the center electrode of an irid-
ium spark plug. Avoid cleaning it or adjusting
its electrode gap.
5. Loosen and remove the spark plug using the
box wrench 2 and driver 3 in the tool bag.
Your outboard motor comes equipped with the
following “standard” spark plug for normal
usage.
NGK ILZKR7D8 Standard
NOTICE
Non-resistor types of spark plugs will inter-
fere with the function of the electronic igni-
tion, causing misfiring, or causing problems
with other electronic boat equipment and
accessories.
Use ONLY resistor type spark plugs in your
outboard motor.
