84
1. Turn the engine off and allow it to cool.
2. Remove the motor cover.
3. Remove the rear panel bolts and rear panel
1.
4. Disconnect the PTT cables from the clamp
2. Remove the side cover bolts and star-
board side cover 3.
5. Turn the boat handle to the left so that the
outboard motor’s rudder angle becomes the
largest.
6. Inject approximately 10 grams of grease at
initial 20 hours.
Inject approximately 5 grams of grease at
every 100 hours (12 months).
NOTE:
If grease will not inject into the fitting, consult
your Authorized Suzuki Marine Dealer.
NOTICE
Using a hydraulic or air powered grease gun
to service the grease nipple
A
on the mount
oil seal cover may cause damage to the oil
seal.
Do not use powered grease guns when servic-
ing grease nipple
A
on the mount oil seal
cover.
To Next Page
