14
Air-vent screw
Fuel hose
Priming bulb
FUEL TANK
Remote control handle
Warm-up lever
Lock-out
lever
Ignition key
Emergency stop switch
Throttle tension adjuster
REMOTE CONTROL BOX
Power tilt (P.T.) switch
(DF9.9BT/20AT)
