(Continued)
3. at t a c h i n g t h e pr i v a c Y bo a r D
A. Align the Privacy Board to the backside
of the Leg Stands.
B. Privacy Board Installation
First attach the back board to the top of the piano legs as
shown with M6x15. Then use the M4x16 Self-tapping screw to
attach the bottom.
IMPORTANT!
Do not over tighten the screws.
4. at t a c h i n g t h e pi a n o
t o t h e st a n D
5. pi a n o bo D Y in s t a l l a t i o n
A. Using two people, lift the Piano onto the Leg Stands
and Pedal Board assembly.
A. Place the piano body on the assembled stand and attach it
with the M6x20 Screw. Install the headphone holder in the proper
location with the 4x12 Self-tapping Screw. Plug the pedal connector
into the socket on the bottom.
Headphone Holder
To Next Page
