7-53
INSPECTION AND MAINTENANCE
75RM0-01E
Front turn signal light (1)
Front position light (2)
Models with halogen headlights
75RM066
Models with LED headlights
62R0306
Rear combination light
75RM070
Remove the bolts (1) and pull the light
housing (2) straight.
NOTE:
When reinstalling the light housing, check
that the clips (3) are properly attached.
Reversing light
62R0122
1) Open the tailgate and remove the trim
(1) of the tailgate.
• Insert a flat blade screwdriver cov-
ered with a soft cloth between the trim
and the tailgate to make a space for
fingers, and then pull out the trim with
your fingers.
(1)
(2)
(1)
(3)
(2)
(1)
(1)
To Next Page
