ILLUSTRATED TABLE OF CONTENTS
52RM0-01E
1. Instrument cluster
(P.2-62, 2-73, 2-90)/
Information display
(P.2-64, 2-76, 2-94)
2. Windshield wiper and washer lever
(P.2-147)/
Rear window wiper/
washer switch (P.2-149)
3. Audio (if equipped) (P.5-33)
4. Hazard warning switch (P.2-147)
5.
Front passenger air bag deactivation
indicator (P.2-60)
/
Theft deterrent light (P.2-16)
6. Ignition switch (vehicle without
keyless push start system) (P.3-3)
7. Engine switch (vehicle with keyless
push start system) (P.3-5)
8. Gearshift lever (P.3-17)
9. AUX/USB socket (if equipped) (P.5-7)
10. Accessory socket (P.5-6)
11. Heating and air conditioning
system (P.5-14)/
Heated rear window switch / heated
outside rearview mirrors switch
(if equipped) (P.2-150)
52RM00060
To Next Page
