11-1
SPECIFICATIONS
52RM0-01E
11
SPECIFICATIONS
NOTE:
Specifications are subject to change without notice.
SHVS: Smart Hybrid Vehicle by Suzuki
M/T: Manual transaxle
A/T: Automatic transaxle
CVT: Continuously variable transaxle
ITEM: Dimensions UNIT: mm (in.)
Overall length 3840 (151.2)
Overall width 1735 (68.3)
Overall height 2WD 1495 (58.9)
4WD 1510 (59.4)
Wheelbase 2450 (96.5)
Track 175/65R15 tire Brake disc 1535 (60.4)
Brake drum 2WD 1530 (60.2)
4WD 1535 (60.4)
185/55R16 tire Brake disc 1525 (60.0)
Brake drum 2WD 1520 (59.8)
4WD 1525 (60.0)
Ground clearance 2WD 120 (4.7)
4WD 145 (5.7)
