2-23
BEFORE DRIVING
52RM0-01E
52RM20130
Seat position adjustment lever (1)
Pull the lever up and slide the seat.
Seatback angle adjustment lever (2)
Pull the lever up and move the seatback.
Seat height adjustment lever (3) (if
equipped)
Pull the lever up to raise the seat. Push the
lever down to lower the seat.
After adjustment, move the seat and seat-
back back and forth to check if it is
securely latched.
