7-43

INSPECTION AND MAINTENANCE

52RM0-01E

52RM70170

2) Remove the wire (3) from a clamp (4).

3) To remove the bulb holder of the bulb

type tail/brake light (5) (if equipped), the

rear turn signal light (6) or the reversing

light (7) from the light housing, turn the

holder counterclockwise and pull it out.

52RM70180

(8) Removal

(9) Installation

4) To remove and install the bulb of the

bulb type tail/brake light (5) (if

equipped), the rear turn signal light (6)

or the reversing light (7), simply pull out

or push in the bulb.

52RM70190

NOTE:

When reinstalling the light housing, check

that the clips are properly attached.

(6)

(7)

(3)

(5)

(4)

EXAMPLE

(5) / (6) / (7)

(8)

(9)

EXAMPLE
