5-25
OTHER CONTROLS AND EQUIPMENT
83RM0-01E
Center outlet
61MM0B047
Move the knob (1) vertically or horizontally to adjust the direction of airflow as desired.
CAUTION
Prolonged exposure to hot air from the heater or air conditioner could result in
low temperature burns. All vehicle occupants, particularly children, the elderly,
those with special needs, individuals with delicate skin, and sleeping individuals,
should maintain sufficient distance from the air outlets to prevent prolonged
exposure to hot airflow.
(1) (1)
Heating System
Description of Controls
61MM0B048
Temperature selector (1)
This is used to select the temperature by
turning the selector.
Blower speed selector (2)
This is used to turn on the blower and to
select blower speed by turning the selec-
tor.
0
1
2
3
4
(1) (4) (3)
(2)
