16.Transfer the upper door to the
appropriate position. Secure the door level,
make the middle hinge axis into the lower
hole of the upper door.Install the hinge②
(provided in the plastic bag)by screws①.
Please hold the upper door by hand when
installing.
12. Lay the refrigerator on soft foam
packaging or similar material. Remove
both adjustable bottom feet parts③, then
remove the lower hinge part① by
unscrewing screws②.
14.Replace the lower hinge part to the left
side and fixing it with the special flange
screws. Replace the adjustablebottom feet
parts to another side and fixing it.
15.Stand the refrigerator upright and
carefully slot the lower door onto the lower
hinge pin and hold in position. Install
middle hinge-left (in the plastic bag)
ensuring the lower door in secured in place.
17.Take out the connector② and③ from
the top left side.Connect① with② ,then
connect③ with the door switch on the
upper hinge cover-left.
18.Install the upper hinge cover② on the
left corner by screw①.
19.Open the upper door and install the
door racks and then close it.
Note:
If your appliance has handle, you have to
reverse handle by follow instructions below.
Lever part① and part④, then loose
screws②. Change handle③ to the right
side, then install screws②, part① and
part④ in turn.
①
②
③
③
①
Adjustable bottom feet part
②
Lower hinge part
③
Special flange screw
15
Special flange screw
Upper hinge-left
①
②
①
②
Door switch
①
①
②
① ②
②
Self-tapping screw
Upper hinge cover-left
13.Loose out the lower hinge pin,change it
to the reverse hole site, then tighten it into
position folllow the picture below.
①
②
③
④
①
②
Handle cover
Special screws
③
Handle
④
Screw hole cover
11. Change screw hole covers and screw
on middle cover plate from left to right (as
shown in figure below).
