SWAGTRON SWAGGER 7 USER MANUAL 21
Section 7
SPECIFICATIONS
Indicators Items Parameters
Dimensions
Opened 41.57 x 16.5 x45.66 in. (1056 x 420 x 1160 mm)
Folded 41.57 x 16.5 x 17.7 in. (1056 x 420 x 450 mm)
Weight Vehicle Weight 27.55 lb. (12.5 kg)
Requirements
Suitable Rider Height 4’ - 6’6” (120 - 200 cm)
Weight Capacity 44 - 265 lb. (20 - 120 kg)
IP Rating IPX4
Working Temp. 32°F to 109°F (0°C to 43°C)
Storage Temp. -4°F to 140°F (-20°C to 60°C)
Performance
Max. Speed* 15.5 mph (25 km/h)
Max. Climbing* 15
o
Range per Charge* 7.9 miles / 12.75km
Brakes Electronic, Rear friction, “Autoguard”
Wheels
Wheel Type Motorized (front), Passive (rear)
Wheel Size 8.5 in.
Tire Material Rubber (air-filled)
Tire Inflation 50 PSI / 3.4 BAR
* Specs provided here assume an average rider weighing approx. 165 lb (75 kg) riding on flat, even pavement. Performance will
vary according to a number of factors, including riding style, rider weight and terrain conditions.
