SWAN SI-100E OWNERS MANUAL 2020.1
OWNERS MANUAL 2019.09
SwanIceShavers.com 1-888-353-3719
12
www.SwanIceShavers.com - 1-888-353-3719 - Info@SwanIceShavers.com
Part # Part Description
27
28
29
30
Rear Guard “M” Stopper
Lower Frame
Front Panel
Base
31
Rubber Feet
32
Gear Box Rubber
33
Switch Cover
34
Protector (Reset Switch)
34-CV
Clear Plastic Protector Cover
35
Motor Switch
36
SS Worm
36-SP
Small Pin for SS Worm
37
Brake Shoe Bracket
38
Worm Spring
39
Brake Shoe
40
Worm Shaft Bracket
41
Ice Block Holder Crank
41-S
Screw for Ice Block Holder Crank
42
Ice Block Holder
43
Gear Grease - NSF, USDA Food Grade 4oz.
44
Plug with Cord
45-L
Thumb Screw (Long)
45-S
Thumb Screw (Short)
46
47
Drain Hose
Brake Adjustment Screw
OWNERS MANUAL 2019.09
SwanIceShavers.com 1-888-353-3719
11
www.SwanIceShavers.com - 1-888-353-3719 - Info@SwanIceShavers.com
To ORDER PARTS contact swaniceshavers.com @ 1-888-353-3719
Part # Part Description
1
Main Shaft Handle
1-S Set Screw for Main Shaft Handle
2
Gear Box Cap
3
Worm Gear
4 Gear Box
5
Worm Gear Rubber
6
Brake Adjustment Hole Plug
7
Main Shaft
8
Polycarbonate Shield
9
Ice Block Holder Cover
10
Shaving Disk with Frame
11
Head Stock Under Cover
12
Blade
13
Blade Support
13-S Screw for Blade Support
13-SA Screw for Blade Adjustment
14
Cutter Block Pin
15
One Touch Spring
16
Blade Adjustment Knob
16-D Decal for Blade Adjustment Knob
17
Drip Tray (new style)
18
Motor Cover Rubber
19
Head Cover
19-S Flat Screw for Head Cover
20
n/a
20-
SS Motor 115 V (w/ SS Worm & Rubber)
20-220-SS Motor - 220 Volt (w/ SS Worm & Rubber)
20-W Motor Leg Base Rubber
21
Brake Worm Gear
21-
LP Large Pin for Brake Worm Gear
21-SP Small Pin for Brake Worm Gear
22
Blade Holder
22-S Screw for Blade Holder
22-W Washer for Blade Holder Screw
23
Head Stock
24
Main Frame Cover
25 Upper Frame
26 Rear Guard "F” Stopper
FOR AUTHENTIC SWAN FACTORY PARTS
1 (800) 742-8342
Complete maintenance videos are available at:
SnoBiz YouTube
