INSTALLATION MANUAL
CFE-Plus MY 01-04
Harness
© 2020 SwedeSolutions the Netherlands - info@swedesolutions.com - www.swedesolutions.com
Instruction# 1697
Version# 1.06
Part# ntbp
EAN#
Author: KW
How-to: use the quick connect tools;
How-to: in case you need to connect a hookup-wire to an existing wire in the car without soldering or specific connect-
ors:
Strip (1) the wire to be connected to at a place where you can reach it good enough to make an ‘eye’ (2) with a sharp ob-
ject and to put the CFE Plus cable (3) trough, twist it and cover it with isolation tape.
1
2
3
