79
3.5 12 Volt DC Fuses
! WARNING: When replacing fuses
always replace a fuse with the correct value.
NEVER replace with a higher value / rating
as this could damage the wiring harness.
If a replacement fuse ‘blows’ do not keep
replacing the fuse as you could damage the
wiring harness. Please investigate the fault
and contact your dealer.
The following table shows the fuse allocation for the 13 fuses fitted to the PSU.
Please note that fuses are dependant on PSU versions, so not all fuses may be present.
Note: Fuses (2-13) have a Red LED below
them which provides indication that the fuse
has blown. The charger fuse has a green
LED which Indicates that the charger is
working.
The following table shows details of the fuse(s) located at the Leisure battery.
Fuse Rating Fuse
Colour
Description
1 25 Amps White Charger
2 7.5 Amps Brown Permanent 12V / Alarm / Fridge Electronics
3 10 Amps Red 12V Sockets / TV Amplifier
4 10 Amps Red Extractor Fans
5 5 Amps Tan Appliances / Hob Ignition / Toilet/ Whale Water Heater
6 10 Amps Red Water Pumps / Tank Heaters
7 7.5 Amps Brown Lighting, Main Lights & Dim Channel 1
8 7.5 Amps Ta n Lighting, Entry Light & Dim Channel 2
9 10 Amps Red Alde Heating / Truma Heating / Whale Air Heater / Marker
Lights / En-Route Sockets & Lights
10 10 Amps Red Auxiliary / Awning Light / Electric Step
11 20 Amps Yellow Fridge 12V
12 15 Amps Blue Towing 12V
13 15 Amps Blue Fridge D+
Fuse Rating Fuse
Colour
Description
Battery 1 40 Amps Orange Fuse remotely located near battery
Battery 2 40 Amps Orange Fuse remotely located near battery 2 (where fitted)
