Wiring Diagrams
Sprite - Cable colour chart
Bulb Chart
Road Lights Bulb type Bulb rating
Front marker lights W5W 12v 5W
Side marker - Low Level W5W 12v 5W
Side marker - High Level R5W 12v 5W
Reversing light P21 12v 21W
Rear indicator light P21 12v 21W
Brake / tail light P21/5W 12v 21W/5W
Fog light P21 12v 21W
Number plate light C5W 12v 5W
Interior / Other Lights Bulb type Bulb rating
Awning Lamp LED FEM0945 complete unit 12v LED
Ceiling light, halogen (living area) Halogen capsule bulb 12v 10W
Ceiling light, halogen (white, shower area) Halogen capsule bulb 12v 10W
Feature light over front seating FEM0937 complete lamp 12v LED
Kitchen light Fluorescent 300mm 12v 8W
Downlight, reading lights GU4 / MR11 Dichroic 12v GU4 10W
Eyelite bunk light T10 (t3 1/4) Wedge 12v 5W
Note: Not all lights and bulbs feature on all models within a range
