Swift Kon-tiki User Manual

Electrical Systems
46
PSU2007
CONTROL PANEL
Overall size (HxWxD) 230 x 370 x 110mm
Weight 3.2Kg
Overall size (HxWxD) 80 x 193 x 40mm
Weight 170g
Fixing centres 195 x 360mm
Fixing centres 175mm
5.2 Dimensions
INPUT 230v
OUTPUT 230v
INPUT 12v
OUTPUT 12v
Integrated CHARGER
Signal INPUT
Data IN / OUT
IP rating
Operating temperature
230 Volts / 0 to 16 Amps
RCD protected, 3 x MCB outputs of 10, 10 and 6A via 2 x 9 way connectors
2 x 20A battery inputs via a 6 way connector
20A total output via 4 16A switched channels protected by 7 fused outputs
via a 15 way connector
Input 110-240 Volts AC +/- 10%, Frequency 50Hz +/- 6%, Current 3.15A max
DC Output 13.5 Volts nominal, Current 16 Amps max (200 Watts)
4 x Fresh water level, 2 x Waste water level, 1 x Engine running via a 8 way
connector
Data communication and power to Control Panel via 20 way header
connector
IP31
Ambient 0 to 35°Centigrade
PSU case temperature with full load 40°C Max
+ / - 10%
Fresh water negative sensed
Waste water positive sensed
5. TECHNICAL DATA & APPROVALS
5.1 Outline Specification

Swift Kon-tiki Specifications

General

Vehicle Type	Motorhome
Base Vehicle	Fiat Ducato
Width	2.35 m
Fuel Tank	90 L
Layout	Fixed island bed
Engine Options	2.3L Multijet
Power	140-180 hp
Transmission Options	Manual, Automatic
Berths	4
Seatbelts	4
Fresh Water Tank	100 L
Heating	Truma Combi
Height	2.90 m
Gross Vehicle Weight	3500 kg
Solar Panel	Optional
