OWNER’S MANUAL

STARTING SERIAL # L112-352001

1602 CORPORATE DRIVE, WARRENSBURG MISSOURI 64093

PHONE: 660-747-8183 FAX: 660-747-8650

TOLL FREE: 1-800-222-8183

Manufacturing quality lawn care equipment since 1945,

Celebrating over 65 years of innovation

18870 REV 12-352

ZTR2760BS, ZTR2760BS-CA, ZTR2460BS, ZTR2460BS-CA,

ZTR2460KA, ZTR2460KA-CA

27 or 24 HP (Briggs & Stratton), 24 HP (Kawasaki) – 60” Wide Cut

w

i

t

h

Patent Pending

Table of Contents

Questions and Answers

S
Sarah MaynardAug 13, 2025
How to start a Swisher ZTR2760BS that won't start?
- P
  peterhawkinsAug 13, 2025
  If your Swisher Lawn Mower engine won't start or is hard to start, try the following: * Fill the fuel tank. * Wait several minutes before attempting to restart. * Replace the spark plug. * Clean or replace the air filter. * Replace the fuel filter. * Drain the fuel tank and carburetor, then refill the tank with fresh gas and replace the fuel filter. * Check all wiring. * Drain the fuel tank and refill with fresh gasoline.
R
Richard HammondAug 17, 2025
Why is my Swisher ZTR2760BS Lawn Mower losing power?
- N
  Nicole SmithAug 17, 2025
  If your Swisher Lawn Mower is losing power, here are a few things you can try: * Set the mower to High Cut (position 1) and reduce speed. * Clean the underside of the mower deck. * Clean or replace the air filter. * Check the oil level and change the oil if needed. * Clean and re-gap or change the spark plug. * Replace the fuel filter. * Drain the fuel tank and refill it with fresh gas. * Drain the fuel tank and carburetor, refill the tank with fresh gas, and replace the fuel filter. * Connect and tighten the spark plug wire. * Clean the engine air screen/fins. * Clean or replace the muffler. * Check all wiring. * Adjust the idler and/or replace the belt.
C
Carlos GoodAug 21, 2025
What to do if my Swisher ZTR2760BS engine will not turn over?
- D
  Danielle AlexanderAug 21, 2025
  If your Swisher Lawn Mower engine will not turn over, consider the following: * Engage the brake. * Push the PTO switch down to disengage. * Recharge or replace the battery. * Replace the fuse. * Clean the battery terminals. * Check all wiring. * Check/replace the ignition switch. * Check/replace the solenoid.
B
brandonwilliamsAug 25, 2025
How to fix an uneven cut with my Swisher ZTR2760BS?
- R
  Robert JensenAug 26, 2025
  To address an uneven cut with your Swisher Lawn Mower, you can: * Replace the blade and tighten the blade bolt. * Clean the underside of the mower deck. * Replace the deck. * Replace the blade driver assembly. Note that the issue may be due to damaged or bent components.
M
Mark AlexanderAug 28, 2025
Why is my Swisher ZTR2760BS Lawn Mower vibrating excessively?
- H
  Heather PearsonAug 28, 2025
  Excessive vibration in your Swisher Lawn Mower may be due to several factors. Try these solutions: * Replace the blade and tighten the blade bolt. * Replace the blade driver. * Tighten any loose parts or replace damaged parts. * Replace the blade driver assembly.
S
Sandra KleinSep 1, 2025
What to do if the battery of my Swisher ZTR2760BS will not charge?
- S
  Stephanie DawsonSep 1, 2025
  If the battery of your Swisher Lawn Mower won't charge, you can try the following: * Replace the battery. * Replace the solenoid. * Check and clean all connections.
L
Levi ManningSep 4, 2025
What causes loss of drive in a Swisher Lawn Mower?
- S
  Sarah CooperSep 5, 2025
  If you experience a loss of drive in your Swisher Lawn Mower: * Ensure the bypass handle is in the drive or disengaged position. * Replace the Hydro belt. * Replace the Idler spring. * Add the specified transmission fluid.
C
Cassie WilliamsSep 9, 2025
How to stop my Swisher Lawn Mower engine from backfiring when turning it off?
- L
  Lisa AndersonSep 9, 2025
  To prevent your Swisher Lawn Mower engine from backfiring when turning it off, move the throttle control to the “SLOW” position and allow it to idle for 30 seconds before stopping the engine.

Summary

Limited Warranty

Introduction and Operation Preparation

General Information

Defines operator position and machine context.

Before Operation & Assembly

Essential pre-operation checks, safety, and uncrating/assembly steps.

Symbols and Decals

Safety Warning Decals

Identification and meaning of critical safety warnings and danger symbols on the machine.

Safety Instructions

General Safety and Operation

Comprehensive safety rules for operating the mower, including personal protection.

Specific Safety Scenarios

Safety guidelines for children, slopes, ROPS use, mowing, and storage.

Customer Responsibilities and Maintenance

Operator Presence and Basic Checks

Safety interlocks, tire, blade, battery care, and charging tips.

Unit Care and Maintenance Schedule

V-belts, engine, unit care, transport safety, and detailed maintenance schedule.

Specifications

Operation and Controls

Features and Starting Procedure

Overview of mower features, controls, and engine starting steps.

Mowing Operation and Adjustments

Grass cutting advice, deck leveling, brake/bypass, and control lever operation.

Fuel Shut-Off Valves

Guidance on the use and function of the fuel shut-off valves for engine operation.

Service and Adjustments

Cutting Height and Brake Adjustments

Steps to adjust cutting height and service the parking brake/bypass system.

Belt Routing and Replacement

Instructions for deck and hydro belt removal, replacement, and routing.

Seat, PTO, and Hydro Expansion Tank

Procedures for seat adjustment, PTO clutch, and hydro expansion tank oil levels.

Wiring Harness Diagrams

Right, Left, and Engine Harnesses

Diagrams illustrating the right, left, and Kawasaki engine wiring harnesses.

Parts Breakdown and Identification

Major Assemblies and Components

Identification of frame, ROPS, hydrostatic, engine, and handle/brake parts.

Idler, Deck, and Blade Assemblies

Breakdown of idler, deck components, belts, and blade driver assemblies.

Troubleshooting Guide

Engine and Drive System Issues

Solutions for engine start problems, drive issues, and vibration.

Cut Quality and Power Loss

Troubleshooting steps for poor cut, loss of power, and battery charging problems.

Mower Identification and Parts Policy

Model Location and Part Usage

Finding model numbers and warnings about using authorized replacement parts.

Replacement Parts Quick Reference

Notes

Swisher History

Swisher ZTR2760BS Specifications

General

Brand	Swisher
Model	ZTR2760BS
Category	Lawn Mower
Language	English
