swissonic V8 - XLR and RCA Connection Pinouts

1 Ground, shielding
2 Signal (in phase, +)
3 Signal (out of phase, –)
4 Shielding on plug housing (option)
Drawing and table indicate the pin assignment of an RCA plug.
1 Signal
2 Ground, shielding
XLR plug (balanced)
RCA connection
Plug and connection assignment
