S-4606
Left side view Front view Right side view
⑴
SDI OUT: 3G/HD/SD-SDI output x2 (BNC)
⑵
LED status indicator
⑶
OPTICAL IN: Optical fiber input (LC)
⑷
DC 12V: 5.5mm pole DC input
3. Working Flow
4. LED status Indicators
⑴
Power (Red): Power indicator
⑵
SDI LOCK (Green): SDI indicator, lights on when there’s SDI input or output recognized
