SWorkz S12-2 - Page 11

11
BAG
D
9
10
108003
M3x10mm FH/ST HEX Screw
x6
220037
220043
332001
108003
108006
108014
104004
220042
220042
104004
330643
101026
106020
108006
220039
101026
SWORKz Aluminum Washer 3X6X1.5mm
x2
330643
Steering Linkage Ball Stud 5mm
x2
106020
M2.5x5mm Hex Socket OH/TP Screw
x2
108006
M3x8mm FH/ST HEX Screw
x2
108006
M3x8mm FH/ST HEX Screw
x8
108014
M3x4mm FH/ST HEX Screw
x1
104004
M3x3mm Set Screw
x3
104004
330156A
115172
PRO TIP:
The 108006 (M3x8 HEX screws) for the side
guard helps adjust the chassis stiffness. With all
the screws (7pcs) on, this will be the most stiff set
up for the chassis and will provide the least grip.
Standard suggestion to start build is with 4 screws.
OPTION:
SW-220037H
S12-2 Side Guard Set in Pro-composite Hard Material
OPTION:
SW-115173 S12-2 Front Sway Bar 1.1mm
SW-115174 S12-2 Front Sway Bar 1.2mm
SW-115175 S12-2 Front Sway Bar 1.3mm
OPTION:
SW-332028 S12-2 Aluminum Front Upper Arm Holder
