SWorkz S12-2 - Page 15

15
17
18
220035
330536
116010
220038
212001
334010
220046(#0)
116019
338011
106014
220046(#0)
330283
Left
Right
106020
M2.5x5mm Hex Socket OH/TP Screw
x2
116010
Ball Bearing 5x10x4mm
x2
330536
Rear Hub Carriers Hing Pin
x2
220035
Insert M3x7xT1mm
x2
106020
116019
Ball Bearing 5X13X4mm
x2
330283
Pin M2x10mm
x2
330283
Pin M2x10mm
x2
106014
M2.0x6mm Hex Socket OH/TP Screw
x2
212001
S12-2 Rear CVD Drive Shaft Set 62mm
x2
332012
S12-2 Rear Drive Shaft (62mm)
x2
332010
S12-2 CVD Axil
x2
332011
S12-2 CVD Axil Holder
x2
330295
S104 CVD Join
x2
Spare Parts of CVD
PRO TIP:
The part 220046 has 3 Rear Hub
Inserts that come in different types
which offers several different rear hub
angles. Please take note when you are
using different insert hub positions, the
rear drive axle also change in distance.
338011
SWORKz Pinion Gear Stopper (5x7x5.1mm)
x2
