SWorkz S12-2 - Page 9

9
6
5
BAG
C
103001
101012
220040
106003
220040
220041
115188
101012
106002
106001
103001
M3 Nut Lock
x1
101012
Washer M3x6xT0.5mm
x2
106002
M3x10mm Hex Socket OH/TP Screw
x2
106003
M3x16mm Hex Socket OH/TP Screw
x1
106002
M3x10mm Hex Socket OH/TP Screw
x8
106002
106002
220044
220041
342001
Use a clamp to tighthen
and turn the slipper
clutch spring all the way
down and then later
open back 3 to 5 turns
before assembling.
PRO TIP
106001
M3x8mm Hex Socket OH/TP Screw
x3
115188
SWORKz 1/10 Slipper Clutch Spring (D1.4x12mm)
x1
115189
SWORKz 1/10 Slipper Clutch Spring (D1.6x12mm)(RD)
x1
0-0.5mm0-0.5mm
