SWorkz S35-4 - Page 18

18
23
22
BAG
E2
BAG
E3
330121B
116006
228001
(#17 #18)
340016
210046
340016
228001(#17 #18)
330124
104010
Left
Right
330124
Pin M3.0x16.8mm
x2
116006
Ball Bearing 8x16x5mm
x2
104010
M5x4mm Set Screw (Flat Bottom)
x2
116004
Ball Bearing 6x10x3mm
x2
101019
SHIM 6.0x10.0x0.2mm
x1
108003
M3x10mm FH/ST HEX Screw
x2
108003
116004
116004
101019
338048
338048
106009
103001
106009
M3x25mm Hex Socket OH/TP Screw
x4
103001
M3 Nut Lock
x4
116006
228002-1
PRO TIP:
The new multi adjustable rear hub can be set
to a wider or a narrow conguration using the
inserts 228001 (#17 #18)
