19
24
25
BAG
E3
103001
103001
330782
330782
330123A
Rear Upper Sus. Arm Turnbuckles
x2
330782
Rear Hub Carriers Hing Pin with Nut
x2
103001
M3 Nut Lock
x2
2503260
(#5 #6 #7)
2503260
(#5 #6 #7)
9.85 mm9.85 mm
22.85 mm22.85 mm
2503260 (#5 #6 #7)
PRO TIP:
The base set up is always by using 2-3mm inserts on
the rear of Hub Carriers Hinge Pins.
The wheel base length should be around 327-328mm.
Longer Upper Arm Linkage Set-up
Shorty Upper Arm Linkage Set-up
330125
338070
330123A
2501121C
2501121C
228006-5
