SWorkz S35-4e EVO - Page 22

22
30
31
BAG
F
106008
106006
228007-2
348008
338128
330245
228019
228019
228007-2
338129
106024
106024
338127
104011
750 BL Motor
is not included
3mm hole
4mm hole
106002
M3x10mm Hex Socket OH/TP Screw
x2
104011
M4x4mm Set Screw (Flat Bottom)
x1
105020
105020
M4x10mm Cap Screw
x2
106008
M3x12mm Hex Socket OH/TP Screw
x2
106006
M3x20mm Hex Socket OH/TP Screw
x2
106010
106010
106002
PRO TIP:
Not only use 105020
(M4x10mm Cap Screw )
but there is also included
105012(M3x10mm Cap
Screw) for lock on your
BL motor.
106024
M4x12mm Hex Socket OH/TP Screw
x2
106010
M3x6mm Hex Socket OH/TP Screw
x2
108003
M3x10mm FH/ST HEX Screw
x3
108010
M4x10mm FH/ST HEX Screw
x4
108003
228002-2E
330767A
108003
108010
