SWorkz S35-4e EVO - Page 28

28
54
34
mm
45
mm
BAG
K
115182
S35-4 Black Competition Front
x2
Shock Spring (US3-Dot)(62X1.6X7.75)
2501121C
Front SWC-115182
Rear SWC-115191
228006
Front 338063A(S)
Rear 338062A(L)
Front 400010(S)
Rear 400009(L)
330134
101011
330557
228006
103004
400020
400006
Shock Seal O-Ring
x8
228016-Seal
Shock Seal Washer 3.6X7X2.5mm
x8
228016-Seal
Shock Seal Washer 3.5X7X1.0mm
x4
103004
M2.5mm Nut Lock
x4
101011
M2.6x6xT0.6mm
x4
400019
Shock Spring Adjust
x4
Nut O-Ring
400020
Shock Seal O-Ring
x4
Slowly push the shock shaft
to the end of shock cap.
Then tight screw M2x4mm
108029
108029
M2.0x4.6mm FH/ST
HEX Screw (1.5mm HexHead)
x4
228016-Seal
Front 330634(S)
Rear 330633(L)
400019
338067
400024S
Standard bladder shock cap assembly note
330560B
338063A
S35-4 Series BBS System Teon Coated Durable Shock Shaft (S)
x2
338062A
S35-4 Series BBS System Teon Coated Durable Shock Shaft (L)
x2
115191
S35 Series Competition Black Line Rear
x2
Shock Spring (RM3-Dot)(80X1.6X10.0)
52
Front 228016-1.2-8
Rear 228016-1.3-8
400006
