SWorkz ZEUS - Page 16

16
19
BAG
E2
Please use the
6x10x0.2mm shim
to adjust play between
the servo saver post
and steering bell crank
plate.
8mm
Please use the
6x10x0.2mm shim
to adjust play between
the servo saver post
and steering bell crank
plate.
8mm
18
108003
108003
116004
101019
116004
Ball Bearing 6x10x3mm
x2
101019
SHIM 6.0x10.0x0.2mm
x1
108003
M3x10mm FH/ST HEX Screw
x2
330113
330251
330251
103001
103001
101021
330251
101021
101021
101021
106007
106007
330135A
115004
106004
330114A
2501122A
2501667-5
2501122B
106004
330827
103001
M3 Nut Lock
x2
116004
Ball Bearing 6x10x3mm
x2
101021
M3x8xT1mm
x4
106007
M3x12mm Hex Socket OH/TP Screw(HT)
x1
