SWorkz ZEUS - Page 17

17
20
21
BAG
E3
2501100
2501098A
2501098A
2501100
330118A
330826
330826
330118A
330252
330252
Screw and adjust 330118 Knuckle
Pivot Ball Nut so as the pivot ball can
be moved smoothly.
Left
Right
330110
330112
330111
330552
116012
116006
330124
104010
330121A
330111
Pin M2.5x14.8mm
x2
116012
Ball Bearing 15x21x4mm
x2
116006
Ball Bearing 8x16x5mm
x2
330124
Pin M3.0x16.8mm
x2
104010
M5x4mm Set Screw (Flat Bottom)
x2
106002
106002
M3x10mm Hex Socket OH/TP Screw
x4
