SWR Henry the 8x8 - Page 6

Panel A
(top chamber)
Tweeter Attenuator
Control
Panel B
(bottom chamber)
1/4" Input 1/4" Output Speakon Input Speakon Output
1/4" Input
Speakon Input
INPUT PANEL DIAGRAMS
Megoliath
4 • BASS SPEAKER ENCLOSURES OWNER’S MANUAL
