Rinse all three items in clean water.
Reassemble the check valve components in the sequence
shown.
Thread the check valve assembly back into pump outlet.
Inspect the float and pump switch for proper operation.
Ensure the float arm moves freely and that the switch
operates. Take care not to bend or damage the float arm.
Using a Philips screwdriver, remove the five screws
from the impeller plate.
07-01922C F532-120V 2015-03 Warranty 07-01939 14 Aramsco
