E1
F1
F2
E2
OK
The mount is designed for the separated headrest, some cars/vans don't
have separated headrest, if the seats look like as below, you must follow the
below installation to fit the mount.
b
seat.
a
OK
Be sure to complete the installation then use SDVD8716D in the car.
For SDVD8716D installation is recommended that the DVD Player
is on the LEFT headrest, to ensure a neat cable run to the monitor,
as shown below:
Let the belts crossing horizontally to the
top seat and engage the 2 trident clips.
Ensure clips are securely fastened
OK
9
8
