Listening to the Radio
1
Antenna
D
O
WN
UP
9
++ ++ ++ ++
++ ++ ++ ++
++ ++ ++ ++
++ ++ ++ ++
Rotate the FM/AM/CD/PHONO knob to
select FM or AM.
Tune to the desired frequency.2
For optimal FM reception be sure to stretch the built-in
FM antenna wire located at the lower back of the unit
and move it around until the station you have tuned in
is being received clearly.
140
A
1
Specifications
Output Power : 2.0W + 2.0W
FM frequency Range : 87.5 to 108.5MHz
AM frequency Range : 525 to 1710KHz
SPEAKER : Impedance: 8 ohms
Input power: Max.3W
Power source :120V AC, 60Hz
Power Consumption :14W
Dimension(W X H X D) :19 X 13.9 X 11.9 (approx.)
