SYM 12. BODY COVER
12-9
Remove the 4 screws between the rear
center cover and the left/right body cover.
Remove the 4 screws between the rear
fender and the left/right body cover.
Remove the 2 screws between the rear
fender and the rear center cover.
Remove the rear fender.
Remove the rear center cover.
Remove the left/right body cover.
Installation
Install the body cover、rear center cover and
rear fender according to the reverse
procedure of removal.
4 screws
Screws 2×2
Screws1×2
