clockwise to reduce the amount of limiting. If you do not have a clearly identified need to peak
limit your signal, then we recommend that you turn the PEAK LIMIT control to the fully clockwise
BYPASS position.
The SYSTEM BYPASS/IN button
The B
YPASS/IN button places the 422 in either BYPASS or IN (CIRCUIT) modes. In BYPASS mode the
incoming signals are directly routed (via relays) to the 422's outputs, thereby bypassing any
internal circuitry. In BYPASS mode the front panel rotary controls have no effect on the operation of
the 422. A red LED indicates BYPASS status, while a green LED indicates IN status.
The I
NPUT AND OUTPUT level meters
The INPUT and OUTPUT level meters are calibrated in VU (volume units). The meters read the
greater of either left or right channel signal levels. The meters give an indication of absolute signal
levels, and show the exact relationship between input and output signals as a result of various
settings of the 422's controls.
