Symetrix 422 - Page 8

422
6
Male 1/4" tip-ring-sleeve plug
Tip = high
Ring = low
Sleeve = ground
Male 1/4" tip-sleeve plug
Tip = high
Sleeve = ground
Male 1/4" tip-ring-sleeve plug
Tip = high
Ring = low
Sleeve = ground
Male 1/4" tip-sleeve plug
Tip = high
Sleeve = ground
Ring
Sleeve
Tip Ring
Sleeve
Tip
Sleeve
Tip
Sleeve
Tip
(Balanced)
(Balanced)
(Balanced)
(Unbalanced)
422 Output
Destination device input
Female XLR
Pin 1 = ground
Pin 2 = high
Pin 3 = low
Male XLR
Pin 1 = ground
Pin 2 = high
Pin 3 = low
2
2
3
3
1
1
Female XLR
Pin 1 = ground
Pin 2 = high
Pin 3 = low
2
3
1
Male 1/4" tip-ring-sleeve plug
Tip = high
Ring = low
Sleeve = ground
Ring
Sleeve
Tip
Male 1/4" tip-ring-sleeve plug
Tip = high
Ring = low
Sleeve = ground
Male 1/4" tip-ring-sleeve plug
Tip = high
Ring = low
Sleeve = ground
Male 1/4" tip-sleeve plug
Tip = high
Sleeve = ground
Male 1/4" tip-ring-sleeve plug
Tip = high
Ring = low
Sleeve = ground
Male 1/4" tip-sleeve plug
Tip = high
Sleeve = ground
Ring
Ring
Sleeve
Sleeve
Tip
Tip
Ring
Sleeve
Tip
Sleeve
Tip
Sleeve
Tip
Male XLR
Pin 1 = ground
Pin 2 = high
Pin 3 = low
2
3
1
Source device output
(Balanced)
(Balanced)
(Balanced)
(Unbalanced)
Female XLR
Pin 1 = ground
Pin 2 = high
Pin 3 = low
Male XLR
Pin 1 = ground
Pin 2 = high
Pin 3 = low
2
2
3
3
1
1
422 Input
