AURORA WEBLINK (AWL) INSTALLATION GUIDE
2
IG2001EW
Aurora WebLink (AWL) Installation and Confi guration
Compatibility
The Symphony Aurora WebLink (AWL) system is backward compatible to several 5 and 7 Series packaged models that support
Aurora ABC and have a communicating thermostat. Before applying the AWL to the heat pump, make sure both the ABC, AXB (if
equipped), and communicating thermostats (TPCC32U01, TPCM32U03A, TPCM32U04A, or MasterStat,) have the latest fi rmware.
Using the AID Tool, confi rm that the fi rmware versions meet the requirements in the Compatibility table (Reference the chart be-
low) before installing AWL. Visit www.auroracontrols.com/toolbox to obtain the latest fi rmware if needed.
Without a communicating thermostat the system is NOT compatible. A communicating thermostat can however replace a 24V
thermostat and provide compatibility for relatively low cost to the homeowner. The IntelliZone and IntelliZone2 ● 24V are NOT
compatible with Symphony since neither are fully communicating systems. For systems with TPCM thermostats, a revision “A” mod-
el will need to be used for compatibility. Early 5 Series units with base controls were shipped with ABC Rev1 boards. If you have an
ABC Rev1 board it will need to be replaced with p/n 17X553-00.
Sensor Kit Options
Sensor kits are all optional but obviously with more sensors, more data can be gathered and transmitted for service use. Without
an AXB, energy data cannot be collected. Sensor kits can be added to existing heat pumps. (5 and 7 Series only)
The optional sensor kits are:
• AXB Kit - 5SAK
• Refrigeration Monitoring Kit (AXB board required) - 5SRK
• Performance Monitoring Kit (AXB board required) 5SPKS-HW or 5SPKL-HW
Symphony Compatibility Chart
Control
Board
ABC Firmware
Version
AXB Firmware
Version
Communicating
Thermostats
IntelliZone2
Symphony/
AWL Compatible
TPCC TPCMA**
E Series - All
Premier2 NA NA NA NA NA Not Compatible
Envision - All Premier2 NA NA NA NA NA Not Compatible
Synergy and 3D - All Premier2 NA NA NA NA NA Not Compatible
NSW - All EW NA NA NA NA NA Not Compatible
NDW - All FX10 NA NA NA NA NA Not Compatible
NDZ/NDS Splits - All
Premier2 &
ABC
NA NA NA NA NA Not Compatible
Legend - All Premier2 NA NA NA NA NA Not Compatible
3 Series* - LD*
Intro to Symphony Launch
ABC Rev2 2.02 or less NA 1.06 or less 2.00 or less
Not compatible
with IZ2 24V
Yes but needs
Software Update
3 Series* -LD* -
Post Symphony Launch
ABC Rev2
≥3.00
(≥2.02 W29)
NA
≥3.00
(≥1.07)
≥3.00
Not compatible
with IZ2 24V
Yes no changes
5 Series*
#
- NSV/H-NDV/H
- “F” vintage
(Intro 3/12-6/12)
ABC Rev1 1.02 or less NA 1.06 or less 2.00 or less 1.08 or less
Yes but Replace ABC Rev1
with new ABC Rev2 board
& maybe software updated
5 Series* - NSV/H-NDV/H
“G” vintage (Shipped 6/12
to Symphony Launch)
ABC Rev2 2.02 or less
optional 1.01
or less
1.06 or less 2.00 or less 1.08 or less
Yes but needs
Software Update
5 Series* - “G” vintage
(Post Symphony Launch)
ABC Rev2
≥3.00
(≥2.02 W29)
≥2.00
(1.01 W09 or
greater)
≥3.00
(≥1.07)
≥3.00
≥2.00
(≥1.08 Z20)
Yes no changes
7 Series -
(From Introduction to
Symphony Launch)
ABC Rev2 2.04 or less 1.01 or less 1.06 or less 2.00 or less 1.08 or less
Yes but needs
Software Update
7 Series -
(Post Symphony Launch)
ABC Rev2
≥3.00
(≥2.04 W29)
≥2.00
(1.01 W09 or
greater)
≥3.00
(≥1.07)
≥3.00
≥2.00
(≥1.08 Z20)
Yes no changes
Rev: 5/4/15 RRB
Software versions in parenthesis are compatible, but were earlier versions used during fi eld trials. These software versions should be updated to
the latest versions at the earliest convenience.
* Although the 3 Series (and 5 Series without AXB) are compatible and will provide the consumer with wireless thermostat functionality, the
limitation remains that very little sensor data can be transmitted without an AXB expansion board. The AXB is not available on the 3 Series.
** The existing TPCM32U03 or U04 monochrome communicating thermostat is NOT compatible with the Symphony/AWL and will need replaced
with the TPCM32U03A or U04A or the TPCC thermostat with appropriate fi rmware version.
# Early shipments of the 5 Series with base control only (no AXB) included the ABC Rev 1 and will need to be replaced with the ABC Rev 2 for
Symphony Compatibility.
ABC Rev1 versus Rev2 can be identifi ed per the photos included in this document.
