SyncMOS Technologies International MSM9066 - Introduction; Top View of MSM9066

SyncMOS MSM9066
User’s Manual
Specifications subject to change without notice, contact your sales representatives for the most recent information.
2
1 Introduction
1.1 MSM9066 supports ICP and allows users to easily program a code into SM39RXX Series and
SM59RXX Series without having to program the ISP Service CODE into Target IC. The product
also supports SM59XX Series, SM39RXX Series and SM59RXX Series ISP.
1.2 Supportable interfaces: USB.
2 Top View of MSM9066
[ISP]
VCC
GND
N/A
RxD
TxD
Button
[ICP]
VCC
GND
N/A
CLK
DATA
Power
(Red LED)
Busy
(Yellow LED)
Good
(Green LED)
Fail
(Red LED)
Supply Power
(Blue LED)
