Synology DiskStation DS413j - Page 7

7 Chapter 2: Hardware Setup
3 Load the hard disk in the hard drive tray.
 For 3.5” Hard Disk: Place the hard disk in the hard drive tray, and then tighten the screws to secure the
hard disk.
 For 2.5” Hard Disk: Place the hard disk in the blue area (shown below) of the hard drive tray, turn the tray
upside down, and then tighten the screws to secure the hard disk.
4 Insert the loaded hard drive tray into the empty hard drive bay.
Important: Make sure the tray is pushed in all the way. Otherwise, the hard disk might not be able to function
properly.
5 Repeat the steps above to assemble the other hard disks you have prepared.
