Q960 Sequential Controller
Sep 2014
The Q960 Sequential Controller is an 8-stage sequencer with 3 rows. An internal oscillator can control
the shifting speed, or an external source. Stages can also be selected manually or from external gates.
The Q960 can be used a 24-stage sequencer using the Q962 Sequential Switch module.
Internal oscillator with
manual or voltage control
of start/stop and speed.
A lamp indicates which
stage is active. The
active stage knobs produce
voltage at the output.
Sets range of the
voltage outputs.
Control Input is a
1V/Octave control of
the internal oscillator
so the sequencer can
be used as a waveform
generator.
Oscillator output is a
90% pulse that can
drive envelope
generators.
Each stage can be
activated by a gate
or by a button.
Each stage has a gate
output (100% duty cycle).
Manual shift or exter-
nal shift to next stage.
The 3rd row knobs can
be used to control how
long each stage stays
active.
