Hot Runner System Installation Guide
Service and Maintenance / Actuator HB Series
8.1.1.2 Overview of the described actuators
This manual describes the assembly process to build the HB Series Actuators. The Actuator parts are
identied with the numbers indicated in the following gure, which shows the components.
NOTICE
Always tighten the screws to the torques specified in the respective table in section 13.
