TPMS TT02 User Guide
Sysgration Confidential 18
If Success,
TT02 --> COMPUTER: "$RAZVOOOO.O #"12 bytes
- V = positive/negative characters, ‘-’ or ‘+’
- OOOO.O = Z- Acceleration value(Oct)
Ex: VOOOO.O = “-0002.5”, Z- Acceleration is -2.5G
If Fail,
TT02 --> COMPUTER: "$RAZFAIL#" 9 bytes
Read Firmware Version
COMPUTER --> TT02: "$RV#", 4 bytes
If Success,
TT02 --> COMPUTER: "$RVOOO#" 7 bytes
- OOO = Firmware Version (Oct)
Ex:OOO =007 , Firmware Version is 0.0.7
If Fail,
TT02 --> COMPUTER: "$RVFAIL#" 8 bytes
Enter DFU Mode
COMPUTER --> TT02: "$ZDFU#", 6 bytes
If Success,
TT02 will reset to DFU bootloader mode, screen will clear.
Enter TEST Mode
COMPUTER --> TT02: "$ZT#", 4 bytes,
If Success, TT02 LED will display black screen.
Press TT02 TRIGGER button , TT02 --> COMPUTER: "$ZTT#" 5 BYTE
Press TT02 CANCEL button , TT02 --> COMPUTER: "$ZTC#" 5 BYTE
Press TT02 OK button , TT02 --> COMPUTER: "$ZTO#" 5 BYTE
Press TT02 POWER button , TT02 --> COMPUTER: "$ZTP#" 5 BYTE
Press TT02 UP button , TT02 --> COMPUTER: "$ZTU#" 5 BYTE
Press TT02 DOWN button , TT02 --> COMPUTER: "$ZTD#" 5 BYTE
Press TT02 LEFT button , TT02 --> COMPUTER: "$ZTL#" 5 BYTE
Press TT02 RIGHT button , TT02 --> COMPUTER: "$ZTR#" 5 BYTE
If want to exit test mode, can use “reset to default” command:
COMPUTER --> TT02: "$ZD#", 4 bytes
Read TT02 Battery Voltage (Test Mode only)
COMPUTER --> TT02: "$ZTBAT#", 7 bytes,
If Success,
TT02 --> COMPUTER: "$ZTBATVVVV#" , 11 bytes
