TPMS TT02 User Guide
Sysgration Confidential 19
- VVVV = Battery voltage (Oct)
Ex:VVVV =8315 , TT02 battery voltage is 8315 mV
Set Backlight ON/OFF (Test Mode only)
COMPUTER --> TT02: "$ZTBKLX#", 8 bytes,
- $ZTBKLX# = Command Code
- $ZTBKLX# = Backlight ON or Backlight OFF, “$ZTBKL1#” : ON, “$ZTBKL0#” : OFF
If Success,
TT02 --> COMPUTER: "$ZTBKLOK#" , 9 bytes
Set Buzzer ON/OFF (Test Mode only)
COMPUTER --> TT02: "$ZTBUZX#", 8 bytes,
- $ZTBUZX# = Command Code
- $ZTBUZX# = Buzzer ON or Buzzer OFF , “$ZTBUZ1#” : ON, “$ZTBUZ0#” : OFF
-
If Success,
TT02 --> COMPUTER: "$ZTBUZOK#" , 9 bytes
Get Charging State (Test Mode Only)
COMPUTER --> TT02: "$ZTCHA#", 7 bytes,
If Success,
TT02 --> COMPUTER: "$ZTCHAX#" , 8 bytes
- $ZTCHAX# = Command Code
- $ZTCHAX# = Charging state, “$ZTCHA1#” : Is Charging, “$ZTCHA0#” : Not Charging.
Set LF Power Level (Test Mode Only)
COMPUTER --> TT02: "$ZTLFX#", 7 bytes,
- $ZTLFX# = Command Code
- $ZTLFX# = Level Value, “$ZTLFH#” : High Level, “$ZTLFN#” : Normal Level.
If Success,
TT02 --> COMPUTER: "$ZTLFOK#" , 8 bytes
