System Cleaners MS1-10 - Page 55

Version 1 (03.2020. EN) (MS1-10, MSC1-10)
Page 55 of 71
03-705110
Item
Part Number
Description
Material
1
30-740483
Flexi clamps ø48,3
-
2
17-010010
O-ring 46x3
NBR
3
08-000801
Nut M8
A2
4
08-800835
Cheese-head screw M8x35
A2
5
06-000650
Pump CRNE 3-8 A-CA-GI-E-HQQE
-
6
08-201211
Set screw M12x45
A2
7
08-001201
Lock nut M12
A2
8
08-301202
Disc washer ø12
A2
9
25-250150
Outlet pipe MS1-10/AMM50-10
AISI 304
10
05-040097
Inlet pipe 3/4" BSP MS1-10/AMM50-10/AMM50-10 Vemag
-
