System Cleaners S4 - Page 13

Version 5 (05.2018. EN) (S4)
Page 13 of 52
Pos.
Part no.
Description
Material
Version
1
08-000502
Lock nut M5
A2
All
2
08-000602
Lock nut M6
A2
All
4
08-100501
Screw button head M5x10
A2
All
5
08-100505
Screw M5x10 cylinder head
A2
All
6
08-100512
Screw fillister head M5x10
A2
All
7
08-100606
Coach screw M6x50
A2
All
8
08-800807
Cheese-head screw M8x50
A2
All
9
08-200606
Set screw M6x16
A2
All
10
08-300602
Disc washer ø6
A2
All
11
08-300605
Disc washer ø6
Nylon
All
12
08-900008
Rawlplugs S 8
PVC
All
13
15-000010
Adapter ø8x1/4" NPT SS
AISI 304
NPT
14
15-000011
Air fitting 1/4"x8 elbow
Nickel-plated brass/Plastic
All
15
15-000061
Air fitting 8x8 elbow
Plastic
All
16
15-000071
Bulkhead Union air ø8
Plastic
All
17
15-010010
Air fitting 1/4"x6 elbow
Nickel-plated brass/Plastic
All
18
15-020050
Air fitting Elbow with throttle 1/8"x4
Plastic/Brass
All
19
15-090402
Color ring 4mm green
Plastic
All
20
15-090406
Color ring 4mm grey
Plastic
All
21
08-100515
Screw buttonhead M5x10
A2
All
22
55-110040
Air hose ø6mm black
PA12
All
23
15-510121
Nipple pipe 1/2"x40mm
AISI 316
3-8 bar
24
15-800032
Union 1/2" with packing, e/i
AISI 316/PTFE
BSP
24
15-800033
Union 1/2" with packing, NPT
AISI 316/PTFE
NPT
25
16-400040
Extension nipple 1/4"x20
Nickel-plated brass
All
26
16-501802
Plug 1/8"
AISI 316
All
27
16-800060
Outlet nipple 1/2"x37 E/I
AISI 304
All
28
17-000072
Gasket 1/8"
Nylon
All
29
17-020080
O-ring 18x2 70 sh
EPDM
All
30
17-030129
O-ring 32x1,5 Viton 75 sh
Viton
All
31
20-000220
Ball valve 1/2" (blue)
AISI 316
BSP
31
20-000226
Ball valve 1/2"NPT (blue)
AISI 316
NPT
32
20-000283
Ball valve 1/2" with actuator
-
All
33
20-200025
Non-return valve air 1/4"
-
All
34
55-110060
Air hose ø6mm red, m
PA12
All
35
20-200410
Non-return valve 1/2"
AISI 304/NBR
All
36
20-300080
Regulator air without filter
Plastic
All
37
20-300141
Filter air 1/4"
Plastic
All
38
20-500061
Strainer 1/2" brass 300 µm
Nickel-plated brass
3-8 bar
39
22-000071
Gauge ø20 0-10 bar
AISI 304/brass/glycerine
All
40
25-000520
Inlet pipe 1/2" BSP
AISI 304
All
41
25-100420
Intermediate pipe 1/2"
AISI 316
All
42
25-200350
Outlet pipe 1/2"
AISI 316
All
43
30-000050
Outlet coupling 1/2"
Special stainless
All
44
41-230302
Door 300 mm
AISI 304
All
45
42-200120
Bracket for pneumatics G5
AISI 304
All
46
42-600038
Hinge for door 300 mm
AISI 304
All
47
42-600039
Hinge for satellite
AISI 304
All
48
43-100080-01
Wall bracket for satellite
-
All
49
46-400301
Housing 300mm S4
AISI 304
All
50
55-100040
Air hose 8mm black
PA12
All
51
72-000030
Nut for lock
Nylon
All
52
72-000040
Lock with hook
AISI 304/Plastic
All
53
72-000051
Strike plate 300 mm cabinet
-
All
54
72-100010
Key for housing
Plastic
All
